Home heating and cooling, explained

Four things decide what your system does

Most of the questions on this site — why a room never warms up, why the air feels clammy, why the bill doubled in January, why a new unit short cycles — come back to four variables. They are worth understanding in order, because fixing the wrong one is how people spend four figures and change nothing.

1. Capacity against load

Load is how much heat your building loses in winter and gains in summer, at a given outdoor temperature. Capacity is how much the equipment can move. The two are matched at a design condition, not at every condition, which is why a system that is correct on the coldest night of the year is oversized on a mild one.

Oversizing is the more common fault, and it is not harmless. A unit with too much capacity satisfies the thermostat quickly and shuts off, which means short run times, less moisture removed from the air in summer, bigger temperature swings, and more wear on the compressor. That is the mechanism behind two separate complaints that look unrelated: a house that is cold and still humid, and a system that keeps starting and stopping.

2. Airflow

Equipment is rated at an airflow. Restrict it and the rated performance stops applying — in heating the coil runs hotter, in cooling it runs colder and can ice up, and in both cases capacity drops while the compressor keeps drawing power. Airflow is restricted by filters, by undersized or crushed return ducts, by closed registers, and by long or badly shaped duct runs.

This is the variable homeowners most often get wrong in the hopeful direction. Adding a fan to a weak branch, or closing registers elsewhere to push air where you want it, does not create airflow — it moves a fixed amount around, and closing registers raises static pressure on a system that may already be struggling.

3. Outdoor temperature, if you have a heat pump

A heat pump is not a fixed-output appliance. Its capacity falls as the outdoor temperature falls, exactly when the building needs more. The temperature at which available capacity and building load cross is the balance point, and below it something else has to make up the difference: electric resistance strips, a gas furnace in a dual-fuel setup, or simply a slow drift downward indoors.

Two behaviours that worry people follow from this and are normal. Supply air from a heat pump is cooler than from a furnace — warm, not hot — so it can feel like a draught. And the outdoor unit periodically reverses to melt frost off its coil, during which it blows cool air indoors and steams outside. Neither is a fault on its own.

4. Controls

The thermostat does not measure the temperature of your house. It measures the temperature of the small volume of air touching it, on whatever wall it was screwed to, often a long time ago by someone whose priority was the convenience of the wiring. Put it in sun, above a lamp, on an exterior wall, or in the draught of a return grille, and it will report a temperature the rest of the house does not share — and the system will faithfully correct a problem that does not exist.

The same applies to settings. A dual-fuel switchover temperature left at the installer default, or auxiliary heat allowed to come on at the slightest setback recovery, will cost real money without ever showing up as a fault.

What you can establish yourself, and what you cannot

A homeowner with no instruments can still produce information a technician would otherwise have to spend billable time collecting. That is the honest ceiling of what this site is for, and it is higher than it sounds.

Things you can establish on your own, with nothing but attention and a notebook:

• How long the system runs and how long it rests, timed over an hour, at a known outdoor temperature.
• Whether a symptom tracks the weather, the time of day, or the thermostat setting — which separates a control problem from a capacity problem.
• Indoor relative humidity alongside temperature. Cheap hygrometers are imprecise in absolute terms but reliable enough for comparing one room with another, or today with yesterday.
• Temperature differences between rooms, measured at the same height, away from sun and vents.
• Which registers move air and which do not, by feel, and whether that changes when interior doors are shut.
• The equipment model numbers from the data plates, and the installation date.

Things that need a technician with instruments, and that no article can substitute for: refrigerant charge, superheat and subcooling, static pressure across the air handler, combustion analysis on anything that burns fuel, electrical fault diagnosis, and any judgement that depends on seeing your actual ductwork.

The division matters because the second list is where money and safety live. A guide that pretends otherwise is selling confidence, not information.

Why the figures here carry labels

Costs and performance numbers on this site are labelled as measured, quoted or sourced, with a date and a region. That is not a formality. A running-cost figure is the product of a tariff, a climate, a building and a piece of equipment, and three of those four change when you cross a border.

The site writes for the United States, Canada, the United Kingdom and Australia, and the same question has four different answers in them — different electricity prices, different gas availability, different efficiency ratings on the box, different rules about who may legally open a refrigerant circuit. Where that changes the answer, the article says so instead of quoting one market as if it were the world.

Where a limit comes from a manufacturer — a maximum line set length, a minimum airflow, a lockout temperature — the article cites the manual rather than repeating a number that has been copied between blogs until nobody knows where it came from. Where manufacturers disagree, which they often do, the article says that too.
